Top Link (Cat.2/2) Ball and Ball, 1 1/8”, Min. Length: 940mm. – S.15311

Sparex Top Link (Cat. 2/2) Ball and Ball, 1 1/8″, Min. Length: 940mm – S.15311

This Sparex Top Link is a versatile and durable option for tractors up to 100hp (75kW). It features a Category 2/2 design with ball ends, a 1 1/8″ thread size, and a minimum length of 940mm. The adjustable length allows for a range of applications, with a maximum length of 1230mm.

Key Features:

• Category: 2/2
• Implement End: Ball
• Tractor End: Ball
• Thread Size: 1 1/8″
• Minimum Length: 940mm (37″)
• Maximum Length: 1230mm (48 1/2″)
• Tube Length: 815mm (32″)
• Centre Tube Size: 42 x 3.25mm
• Tractor End Ball Width: 51mm
• Colour: Gold
• Thread Type: UNC

Specifications:

• A (ins): 32
• A (mm): 815
• B Max. (ins): 48 27/64
• B Max. (mm): 1230
• B Min. (ins): 37
• B Min. (mm): 940
• Brand: Sparex
• Category Implement End: 2
• Category Tractor End: 2
• erp_hazardous: No
• Maximum Length (ins): 48 1/2
• Maximum Length (mm): 1230
• Minimum Length (ins): 37
• Minimum Length (mm): 940
• Related products: 346, 347
• Replacement Implement End: S.347
• Replacement Tractor End: S.346
• Suitable for Tractors up to HP/Kw: 100hp (75kW)
• Tariff Code: 7303009090
• Tube Length (ins): 32
• Tube Length (mm): 815

Please note: This product is not associated with any particular make or model of tractor or OEM part number.
