*SPECIAL PRICE* – Loader Tine – Straight 1100mm, Thread size: M28 x 1.50 (Square) To fit as: KK241166 – S.77035 (Copy)

Loader Tine – Straight 1100mm, Thread Size: M28 x 1.50 (Square)

Introducing the Loader Tine designed for optimal performance and durability. This straight tine, measuring 1100mm in length, is engineered to fit Conus 2 systems and is compatible with various Kverneland and Valpadana models.

Key Features:

• Fitting: Conus 2
• Maximum Tine Diameter: 44mm
• Thread Size: M28 x 1.50 (Metric)
• Profile: Square
• Colour: Red
• Brand: SHW
• Nut Included: Yes (Nut: S.77030)
• Maximum Torque: 700 Nm
• Alternative to: 72485
• Conus Reference: K013
• HD Bush: S.19836
• STD Bush: S.1841
• Tariff Code: 8426990000

Specifications:

• A (mm): 1100
• B (mm): 330
• C (mm): N/A
• Tine Length: 43 inches (1100 mm)

Compatibility:

This loader tine is suitable for various models from Kverneland and Valpadana. Primary OE references include:

• KK241166
• KK241166M28
• 241166M28
• 241166

Important Safety Warning:

For optimal safety and performance, it is crucial to retighten the nuts according to the instructed torque after 5 hours of operation using a torque-controlled spanner.

Enhance your equipment’s efficiency with the reliable and robust Loader Tine from Sparex. Order yours today!
